"현재까지 출시된 도전율측정기 중에서 교정이 가장 간편하다. 센서를 시편에 대고 CAL 버튼을 누르면 끝"
Direct readings in
%IACS or MS/m
10mm diameter measuring
4 × AA cells provide ~100
Lift-off compensation and
High resolution LCD
Battery status shown on
Logging memory for up to 60 measurements Zappitec is introducing the
model 12Z Eddy Current Electrical Conductivity Meter for non-magnetic metals.
The 12Z uses the latest technology to provide an instrument which is
user-friendly and practical to measure electrical conductivity in the
The instrument comes
calibrated with traceable standards, providing reliable readings even when
measuring rough surfaces.
Quality control of raw
materials or finished parts
Lift 0ff compensation allows
non-contact measurements and better measurements on curved surfaces. The
approximate distance from the part being measured is shown in the
Our model 12Z uses advanced
technology to provide high precision measurements with high reliability. LSI
fully integrated analog-digital interfaces provide low noise fast readings.
Internal sensor temperature measurement provides thermal compensation for
A high resolution display
ensures clear visibility of conductivity values while still displaying
additional information about the measurement. Calibration uses a "one point"
calibration method to facilitate use. Certifiable standards are supplied with
